CS Inspection Platform

High-speed inspection for compact environments

The CS platform combines high-speed capability with a compact footprint. Integrated HVLD Slim supports leak testing for lyophilized products, while up to six camera stations detect particles and cosmetic defects with consistent performance.

Benefits

Compact & high-speed

Combine throughput of up to 600 containers per minute with a compact footprint of 1,475 × 1,350 mm.

Reliable leak testing

Integrate HVLD Slim directly into the inspection process to support reliable leak testing for liquid and lyophilized products.

Lyophilized product inspection

Support lyophilized product inspection by integrating Headspace Analysis (HSA) directly into the inspection carousel where required.

Efficient downstream management

Streamline downstream sorting with up to five outfeeds for efficient container handling and process flow.

Specifications

Compare our basic platforms for automated high-speed inspection of vials, ampules, and cartridges.

Machine series	VI	MS	CS
Dimensions basic platform	1,500 x 1,800 mm	1,400 x 1,500 mm	1,475 x 1,350 mm
Throughput (up to)	600 containers/min	600 containers/min	600 containers/min
Max. no. of camera stations (inside carousel)	13 (8)	9 (6)	6 (4)
Container Ø up to	52 mm	52 mm	52 mm
Outfeed channels up to	10	10	5
HVLD integration	HVLD SLIM / UpsideDown	HVLD SLIM / UpsideDown	HVLD SLIM
HSA option	Integration into carousel	Integration into carousel	Integration into carousel
Integrable inspection technologies	Bubble-X, 3D inspection	Bubble-X, 3D inspection	No
Eject-X ready	Yes	Yes	No

Downloads

Documentation

Cover for the CS inspection machine factsheet.

Factsheet: High-speed inspection for stable containers

Learn more about the CS.
